The use of a range extender, installed between a lens and a camera, will extend the focal length and increase the effective aperture (F/number) of a video lens. For example, using the 2XE range extender will extend the focal length by two times (2X) and double the effective aperture of the following lens:

(2X) 50 mm, F/1.3 lens = 100 mm F/2.6

We also offer an extension tube kit (NMV-EXT), which allows you to turn standard fixed focal length lenses into macro lenses. This kit includes six extender tubes (0.5 mm, 1 mm, 5 mm, 10 mm, and 20 mm) for extension from 0.5 mm to 36.5 mm. The tube(s) mount between the camera and the lens, making it possible for you to focus a C-mount lens at a much closer distance than normal.

Extension Tubes

Extension tubes allow you to turn standard fixed focal length lenses into macro lenses. An extension tube kit is available which includes six extender tubes: 0.5 mm, 1 mm, 5 mm, 10 mm, and 22 mm for extension from 0.5 mm to 38.5 mm. The tube(s) mount between the camera and the lens, making it possible for you to focus a C-mount lens at a much closer distance than normal.
